Forklift 3 Ton Transmission for Heli

Product Title: Heli forklift 3t CPCD30 CPCD25 hydraulic gearbox

Product Model: Forklift hydraulic gearbox H93D2-50001-X

The hydraulic gearbox of Heli Forklift requires regular maintenance in accordance with the provisions of the Heli Forklift Maintenance Manual. After repair and maintenance of the Heli forklift transmission box, the following steps are required for inspection:

1. Procedures to clean the oil circuit. Use a special cleaning agent to thoroughly clean the cooler and cooling oil pipe of the Heli forklift gearbox to ensure that there is no debris and the oil passage is unobstructed. Replace the oil pipe of the water tank cooler if necessary;

2. Visually check whether the torque converter is in place;

3. Forklift maintenance personnel need to check whether the positioning pins and various screws between the engine and the Heli forklift gearbox are completely installed.

4. Forklift maintenance personnel need to check whether the torque converter screws are too long and whether the machine is tightly fitted after the installation bolts are tightened;

5. Check the flywheel runout of Heli forklift engine (reference value: below 1.0mm);

6. Heli forklift maintenance personnel need to check whether the gear lever, throttle cable and vacuum line are well adjusted;

7. The maintenance personnel of Heli need to fill the automatic transmission oil specified by the original factory (additional gear oil for manual gear models), and check the oil level.

8. Check that the foot pad of the engine is not damaged;

9. Make sure that the wire insertion and grounding wires are completely installed, and the drive shaft and half shaft are assembled according to regulations;

10. The Heli forklift gearbox is a very important system in the forklift body, which directly affects the safety of the truck. Once the forklift driver finds a problem, he should immediately contact the nearby Heli forklift designated maintenance station for maintenance.

11. Please contact us for maintenance and maintenance instructions of Heli forklift hydraulic transmission box.
